Overband Magnetic Separator

Overband Magnetic Separator is also known as cross belt magnetic separator which mainly consists of strong magnetic plate, steel frame, belt and two metal pulleys that can be driven by a motor with a reducer. It is engineered for hanging over a conveyer belt to remove  ferrous contaminations like bolts,screws,wires etc. from belt conveyed material and widely used in the field of plastic, tire, paper wood, E-Scrap recycling or mining.

Features:

   1. Deep reaching magnetic circuit design to penetrate heavy product burdens.

   2. Strong magnetic field intensity, high gradient and strong attractive force.

   3. Self Cleaning Belt with discharge ribs.

   4. Special sealed bearing block ensure the stable working in harsh environment.

   5. No electric power required to generate magnetic force.

   6. Easy belt adjustment with screw fasten.

   7. Magnetic force will not decrease more than 5% within 8 years.

  Options:

   1. Electric Driven Motor/Hydraulic Driven Motor

   2. Stainless Steel Protection Housing Cover for Belt Running

   3. Stainless Steel Armed Belt

   4. Control Cabinet​

1.Frame material options:steel or stainless steel
2.Surface treatment: painting or brushing
3.Magnetic intensity :400-450GS
4.Working temparature: from 80℃ to 180℃
5.Magnet materials :  Ceramic , Neodymium-Iron-Boron(rare-earth)
6.Custom made :available.your logo/brand/patte can be printed on
7.MOQ:1PC
8.Lead time:30days
9.Packing:wood case
10.Payment term: T/T
11.Loading Port:Ning Bo/ShangHai

About Us

Mag-spring was established in 2003 and is located in Ningbo, Zhejiang Province, China. It is a comprehensive manufacturer of magnetic application products, specializing in the research, design and production of magnetic filters and various magnetic application components.

The company has a group of professional technicians and production equipment, operates strictly in accordance with the ISO9001 quality system, and continuously strengthens internal management. While the company is constantly developing, it pays attention to environmental protection. It is an ISO14001 certified enterprise, and the company's products meet the requirements of the EU ROHS directive.

Based on the enterprise tenet of "efficiency, perfection, harmony and dedication" and the enterprise slogan of "everything we handle must be excellent", with many years of experience in research, design, manufacturing and sales in the field of magnetic products, the company's products have been recognized by many customers at home and abroad. We will sincerely look forward to cooperating with you with high-quality products, preferential prices and the best services.
